Your Location: Home >> Product Center >> LED Corn Light >> LED CFL Corn Light >> Spiral SMD LED CFL Light
| Name: | Spiral SMD LED CFL Light |
|---|---|
| Product name: | Spiral SMD LED CFL Light |
| Available power: | 5W 7W 9W 12W 16W 24W 30W 36W |
| Beam angle: | 360 Degree |
| LED Chip: | Epistar SMD 2835 |
| Lamp Luminous Efficiency(lm/w): | 85 |
| Working Lifetime(Hour): | 35000 |
| Dimension: | 59151mm |
| Base Optional: | E14/ E26 / E27 / B22 |
| Color Temperature(CCT): | 2700~6500K |
| Material: | Glass + Fire Resistence Plistic |
PRODUCT DESCRIPTION
IN-SMD-S-20W SMD 2835 Spiral Shaped LED Corn Bulb Light Lamp LED CFL 5W 7W 9W 12W 16W 20W 24W 30W LED Corn Light
| Product Overview __________________________________________________________________ |
| Infelite Spiral Shaped SMD LED Corn Light Specifications: | ||||
| Item Model: | IN-SMD-S-5W | IN-SMD-S-7W | IN-SMD-S-9W | IN-SMD-S-12W |
| Power Output | 5 Watts | 7 Watts | 9 Watts | 12 Watts |
| Luminous Flux | 450m | 630lm | 810lm | 1080lm |
| LED Quantity(SMD) | 2835/26pcs | 2835/40pcs | 2835/48pcs | 2835/66pcs |
| Unit Size(mm) | 48*105mm | 48*112mm | 48*117mm | 59*141mm |
| Item Model: | IN-SMD-S-16W | IN-SMD-S-20W | IN-SMD-S-24W | IN-SMD-S-30W |
| Power Output | 16 Watts | 20 Watts | 24 Watts | 30 Watts |
| Luminous Flux | 1450lm | 1800lm | 2160lm | 2700lm |
| LED Quantity | 2835/88pcs | 2835/112pcs | 2835/130pcs | 2835/160pcs |
| Unit Size(mm) | 59*151mm | 59*171mm | 80*195mm | 80*205mm |
| Voltage Input | AC85∼265V 50⁄60HZ | |||
| Luminous Intensity | ≥ 90lm/W | |||
| Power Factor | PF >0.85 | |||
| CRI | Ra > 80 | |||
| Viewing Angle | 360 Degrees | |||
| Color Temp.(CCT) | 2800 ∼ 6000K | |||
| Working Temp | -20°C ∼ 50°C | |||
| Driver Type | IC Constant Current | |||
| IP Rating | IP44 Grade | |||
| Lamp Socket | E26/E27/B22/GU24 | |||
| Material | PCB + Glass + Fire Resistence Plistic | |||
| LED Life Span | Over 35,000 Hours | |||
Our led corn light designed according to the compact fluorescent lamp.
1. Energy saving high power LED light to replace the conventional CFL bulb 105W
2. Internal Aluminum sheet for heat dissipation
3. Light is soft and uniform, safe to eyes
4. No uv or IR in the beam,cool light, No heat emission
5. Instant start, No flickering, No humming
6. Easy to install and operate
7. Green and eco-friendly without mercury
8. It's major to replace the CFL with screwed lamp base directly
9. 80% more energy saving compared with conventional street light, CFL, Incandescent light
10. Special surface design with arc, make sure the radiation diameter on the ground is accord with the standards for
Infelite LED Corn Light Product Shaped List: Click To View The Details Of the Product.
| Shaped Type | Power Output | Base Optional |
| Standard Shaped SMD | 5W 7W 9W 12W 16W 24W 30W 36W 40W 50W | E14 E26 E27 B22 |
| Standard Shaped COB | 5W 7W 9W 12W 15W | |
| U Shaped SMD | 5W 7W 9W 12W 16W 24W 30W 36W | |
| U Shaped COB | 5W 7W 9W 12W 16W 20W 24W 30W | |
| Lotus Shaped SMD | 24W 30W 40W 50W | |
| Spiral Shaped SMD | 5W 7W 9W 12W 16W 20W 24W 30W | |
| Spiral Shaped COB | 5W 7W 9W 12W 16W 24W 32W |
| Detailed Images ____________________________________________________________________ |
1.Blister and white box for cardboard inner box, Spiral LED Corn Light 20W unit size: 59mm X59mm X 151mm. 100pcs/Carton.
2. Your logo printed on the inner box or the laser marked on the body of the bulb is available.
3.Neutral white cardbbard innerbox
| Payment & Shipping Method ___________________________________________________ |
1. Payment Method Support: Alibaba Trade Assurance, T/T, Western Union, MoneyGram, Paypal etc.
2.Shipping Method: DHL,UPS,FEDEX,TNT,EMS or appoint by the buyer,but except for mass production item.
3. Produce Time: 3~5 working days for the in stock ones, 7-12 working days for the produced.
4. Delivery Time: Most contry takes 4-10 days, the more precise ref time will be offered when ordering.
